Earthen plaster on conventional walls


Posts: 16
2
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
So, my partner and I are writing an offer on a cute little cabin. It's framed out and the exterior is done, but it needs to be insulated and finished on the inside. FWIW we're in zone 4. I have a bunch of the denim insulation I bought for cheap a few years ago that we're planing to use.

I have some experience with earthen plasters, but only on natural structures like strawbale, cob, earthbag, etc. I am wondering what would be a cost-effective, and more importantly, low impact way to use earthen plaster over conventional framing and insulation. Should we do lath? Should we put up plywood? What will the plaster attach to? Any tips?

Thanks!!!

pollinator
Posts: 4958
1190
transportation duck trees rabbit tiny house chicken earthworks building woodworking
  • Likes 1
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
First off, welcome to Permies!

The second thing is, and this might depend on cost, but I wondered if stapling up chicken wire netting might work to hold your earthen plaster?

rachel johnson
Posts: 16
2
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
I am wondering more about a barrier between the insulation and the plaster. Could I  just do denim insulation, wire, plaster? That seems like it might not be sturdy enough or would have moisture issues, but I'd be happy to be wrong on that.

gardener
Posts: 1749
Location: Kingman, Arizona
506
building solar woodworking rocket stoves wood heat greening the desert
  • Likes 5
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
Hi Rachel,   I would suggest that you need something for the plaster to adhere to that is a little more substantial than just the insulation. Also, the expansion and contraction between the studs and insulation (being dissimilar materials) would most likely cause cracks that will never stop reoccurring. Some sort of stiff and non smooth surface such as conventional steel lathe or more natural reed mat should do the trick. In the days before drywall, the norm was putting up narrow horizontal boards with small spaces between and plastering over that.
Here are some reed mat pictures to give you an idea...




Posts: 165
Location: Idaho
14
books bike solar woodworking wood heat homestead
  • Likes 1
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator

Gerry Parent wrote:Hi Rachel,   I would suggest that you need something for the plaster to adhere to that is a little more substantial than just the insulation. Also, the expansion and contraction between the studs and insulation (being dissimilar materials) would most likely cause cracks that will never stop reoccurring. Some sort of stiff and non smooth surface such as conventional steel lathe or more natural reed mat should do the trick. In the days before drywall, the norm was putting up narrow horizontal boards with small spaces between and plastering over that.
Here are some reed mat pictures to give you an idea...





Hi,

I like your photos. Question for you: Is that simply reed privacy fencing stapled to the wall studs?

Thanks.

Gerry Parent
gardener
Posts: 1749
Location: Kingman, Arizona
506
building solar woodworking rocket stoves wood heat greening the desert
  • Likes 3
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
Yes Rusty, that's all it is.
Just make sure your fasteners penetrate deeply enough into the wood to firmly support the weight of the plaster. Burlap can also be used in more curvy places.

Rusty Bowman
Posts: 165
Location: Idaho
14
books bike solar woodworking wood heat homestead
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator

Gerry Parent wrote:Yes Rusty, that's all it is.
Just make sure your fasteners penetrate deeply enough into the wood to firmly support the weight of the plaster. Burlap can also be used in more curvy places.



Thanks! That's what I was hoping to use in my place I'm currently building. Trying to get an idea of what to expect. How far apart did you staple it, roughly?

Gerry Parent
gardener
Posts: 1749
Location: Kingman, Arizona
506
building solar woodworking rocket stoves wood heat greening the desert
  • Likes 1
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
Those were not my photos Rusty.
Just used them to give an example of what I was referring to the questioner.
If it were me, after stapling, I'd run a strip of thin wood along each stud to help hold the mat in place.

pollinator
Posts: 4848
Location: Bendigo , Australia
403
plumbing earthworks bee building homestead greening the desert
  • Likes 3
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
When wooden lathes were applied years ago each 1 1/4 inch wooden strap was nailed at each stud.
[Thumbnail for download-31.jpg]
showing how plaster grips
showing how plaster grips to the lathe
showing nailing is done

pollinator
Posts: 128
Location: Oklahoma Panhandle
27
  • Mark post as helpful
  • send pies
    Number of slices to send:
    Optional 'thank-you' note:
  • Quote
  • Report post to moderator
Rachel,
How about this?  Did you get an opportunity to use earthen plaster on that cabin?  If so, how did you do/like it?
