anyone ever rip with a cross cut saw?

I hope I'm asking this in the right place.. I wasn't quite sure but since I feel like making use of trees is a permaculture-thing I thought I'd try it here.

I was thinking of asking if anyone knew of a one man 'pit-style' rip saw (ie. with real rip teeth) but at this point, I've kind of figured out that they don't exist.

My specific problem is that I have a 5' log of deodar cedar that's about 12" in diameter and I'd like to get some boards out of it, by hand. No chain saws, etc etc. At least I'd like to try it first that way and fail

I realize that there are several types of teeth patterns - has anyone had any success with one type of tooth pattern over another?

Honestly, I'm kinda stunned that I can't find (online) any solution to the problem of making boards out of a log with hand power. It doesn't seem too crazy a question. Am I looking in the wrong places? Hmm...

Thanks!

ps. Anyone have one I can try out around Eugene Oregon?

I've seen rip saws on ebay but they are pricey. You also need the tools to to sharpen and maintain them which is an art in itself. If I were to get a rip saw I would go for an old one that is taper ground. Anything you would get that is new, rip or crosscut, will be punched from a piece of flat stock. Taper ground saws the side opposite the teeth is narrow than the tooth side.

you might have better luck with wedges and a sledge.

tel jetson wrote:you might have better luck with wedges and a sledge.

I've tried that on a bigger doug fir log I have (24" diameter, 4-5' long) and while I had decent success, it seemed to be more wasteful of the wood. Also, I think I'll need an adz in order to smooth out the bumps, so to speak. It seems to me that logs don't split all that evenly. Of course, I might not be that good with a sledge & wedge.

I believe a froe and mallet is another traditional method. Your log will need to be straight grained. Also something like the crotch of a tree was used to hold the log. Best done when wood is still green and full of moisture. Good luck with that.

http://www.woodweb.com/knowledge_base/HandPowered_Saws_for_Milling_Logs.html
http://japanwoodworker.com/dept.asp?s=JapanWoodworker&dept_id=13090

This is what you want, Pax hand saws:
http://www.toolsforworkingwood.com//Merchant/merchant.mvc?Screen=PROD&Store_Code=toolshop&Product_Code=PZ-HS303.XX&Category_Code=CPX

Deb Suran wrote:This is what you want, Pax hand saws:
http://www.toolsforworkingwood.com//Merchant/merchant.mvc?Screen=PROD&Store_Code=toolshop&Product_Code=PZ-HS303.XX&Category_Code=CPX

Those are for ripping boards they will never work on logs

Chuck Freeman wrote:Those are for ripping boards they will never work on logs

The 28" rip saw would work with a lot of effort however having used a similar styled antique saw and the Japanese rip saw from the previous post the 16" (420mm) Japanese saw works better, faster and with less waste.

thre are several videos on youtube on how to use wedges and a froe to split rough planks, then flatten with adze,draw knife ,scrub plane,joiner plane,jack plane and so on...

i found 1 place that does sell a PIT SAW,amazingly enough!
http://www.frogwoodtools.com/Catalog/65.htm
there you'll also find 1 man saws, froes etc for timber framing.

be ready for some work! just ask this poor sap haha http://www.youtube.com/watch?v=IuHLqtBYJWE

i use a chainsaw mill, and believe me that is plenty hard enough !

You have to watch new saws as they are all punched from flat stock. Old ones are ground so the back is thinner that the front(the side with the teeth). Filing and setting rip saw and crosscuts is an art and the tools to do it don't come cheap either. If it was me and I really wanted to use hand tools to work with I would do the research then bite the bullet and go with the old stuff. There also some very books put out by the Forest Service that tell how to use and maintain crosscuts and axes. One is The Crosscut Saw Manual the other one is Saws that Sing. There is also a good one on Axes called An Ax to Grind.

This is the only address I can find but I'm sure you could Google them up pretty easy:
USDA FS, Missoula Technology and Development Center
5785 Hwy. 10 West
Missoula, MT 59808–9361
Phone: 406–329–3978
Fax: 406–329–3719
E-mail: wo_mtdc_pubs@fs.fed.us

I've ripped planks with rip saws, split them with wedges and froes, and used band saws and chain saw mills. It is just my opinion but for all round milling you can't beat an Alaskan Chainsaw Mill.

Monte what kind of chainsaw mill is the one on the carriage? Not the Alaskan mill but the second one?

Thanks I'll have to do some looking when I have some time, looks like a cheap alternative to a bandsaw.

i also like the bandsaw sleds for slabbing smaller lengths . i can only do 15" resaw but that's plenty for small craft i do with little pieces.

Monte, what advantages do you find in using the track/carriage mounted rig?
i love my alaskan mill...
i find the best part of a chainsaw mill is the light weight,portability and quick setup.
i guess i feel like if i need to bring the log to the mill i'd be better off with a bandmill. or that "rip-saw chainsaw bandmill attachemnt looks pretty nifty,albeit a bit pricey.
i've seen other portable mini-bandmills too. like "lumber smith"

Monte, what advantages do you find in using the track/carriage mounted rig?
i love my alaskan mill...
i find the best part of a chainsaw mill is the light weight,portability and quick setup.
i guess i feel like if i need to bring the log to the mill i'd be better off with a bandmill. or that "rip-saw chainsaw bandmill attachemnt looks pretty nifty,albeit a bit pricey.
i've seen other portable mini-bandmills too. like "lumber smith"

Biggest advantages are that we don't have to place the 9ft EZ Rails in place, and affix to the log for the first cut. Also we don't have to hand adjust the depth of cut on the Alaskan mill.
On the carriage mill I just use the battery drill with socket to raise the chainsaw to the depth of cut desired.

I still like using the Alaskan mill in certain situations. On a very large log, I can square the log and use Mini Mill II to reduce size. It works for logs that aren't easily transported by our tractors with forks.

Owning a bandmill big enough to do a proper job is very pricey. It is my understanding that bandmills under about 15 HP are pretty under-powered.

If we have a large amount of logs, like now due to storm damage (over 100) we are having portable bandmill and operator come in for 2-3 days to slab the wood. I will stack, sticker, store, and slowly dry in open sided barns.

We have to have a couple of chainsaws to manage downed and damaged trees anyway. The Alaskan and small carriage mill allow us to keep up with normal amount of annual timber management and salvage for lumber. Remaining stuff is used for raised beds, biochar, and firewood.

I can resharpen chainsaw chain easily and cheaply myself. Buying and maintaining large bandsaw blades requires more skill, equipment and expense.

Everyone has to decide what is right for them, depending on their circumstances.

Regards,
Monte Hines

I built a chainsaw mill a few years back from plans from here - http://www.procutportablesawmills.com/

It works great.

You could however, come up with your own design. It's not rocket science.

>
